Ziggo zenders found maar zwart


Recommended Posts

2018/03/25 16:24:20 55B78E52 c      (ecm) dvbapi_local (5644@000000/01F4/4C23/4C:A56519013DC2B0E1B0776C440EE0B407): found (248 ms) by ziggo
2018/03/25 16:24:22 55B78E52 c      (ecm) dvbapi_local (5644@000000/000B/4B1A/4C:B1F1F74F0706CABA1C3C59C0787472C2): found (237 ms) by ziggo
2018/03/25 16:24:28 5AC6DC9B r   (reader) ziggo [irdeto] dvbapi_local emmtype=shared, len=63 (hex: 0x3F), cnt=0: written (167 ms)
2018/03/25 16:24:36 55B78E52 c   (dvbapi) Demuxer 0 stop descrambling program number 4C23 (1801@000000:4C23 unknown)
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 0 CAID: 1801 ECM_PID: 0037 PROVID: 000000
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 1 CAID: 1850 ECM_PID: 0097 PROVID: 000000
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 2 CAID: 0602 ECM_PID: 00C9 PROVID: 000000
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 3 CAID: 0604 ECM_PID: 012D PROVID: 000000
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 4 CAID: 0606 ECM_PID: 0191 PROVID: 000000
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 5 CAID: 1868 ECM_PID: 01C3 PROVID: 000000
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 found 6 ECMpids and 3 STREAMpids in caPMT
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 trying to descramble PID 3 CAID 0604 PROVID 000000 ECMPID 012D ANY CHID PMTPID 15E0 VPID 15E1
2018/03/25 16:24:38 55B78E52 c   (dvbapi) Demuxer 0 found 6 ECMpids and 3 STREAMpids in PMT
2018/03/25 16:24:39 55B78E52 c      (ecm) dvbapi_local (5644@000000/0027/4CC5/4C:A598B99C0C726621DE358088A1D3C4B7): found (262 ms) by ziggo
2018/03/25 16:24:39 5AC6DC9B r   (reader) ziggo [irdeto] dvbapi_local emmtype=global, len=43 (hex: 0x2B), cnt=0: written (123 ms)
2018/03/25 16:24:39 55B78E52 c      (ecm) dvbapi_local (5644@000000/0027/4CC5/4C:7D02D131F10ED422D04FEC248CA1F184): found (300 ms) by ziggo
2018/03/25 16:24:42 55B78E52 c      (ecm) dvbapi_local (5644@000000/000B/4B1A/4C:F54084F6C8241982B7A48157703A1A52): found (244 ms) by ziggo
2018/03/25 16:20:22 00000000 s      (net) cs357x: initialized (fd=4, port=16001, ip=192.168.178.29)
2018/03/25 16:20:22 00000000 s   (reader) ziggo [internal] creating thread for device /dev/sci0
2018/03/25 16:20:22 00000000 s     (stat) loadbalancer: could not open /tmp/.oscam/stat for reading (errno=2 No such file or directory)
2018/03/25 16:20:22 00000000 s (emmcache) loaded 0 emmcache records from /etc/tuxbox/config/oscam.emmcache in 0 ms
2018/03/25 16:20:22 00000000 s (emmcache) loaded 0 emmstat records from /etc/tuxbox/config/oscam.emmstat in 1 ms
2018/03/25 16:20:22 00000000 s (anticasc) anti cascading disabled
2018/03/25 16:20:22 5AC6DC9B r   (reader) ziggo [internal] Reader initialized (device=/dev/sci0, detect=cd, pll max=27.00 MHz, wanted mhz=4.50 MHz)
2018/03/25 16:20:22 5AC6DC9B r   (reader) ziggo [internal] Reader sci internal, detected box type: vuultimo
2018/03/25 16:20:22 55B78E52 c   (client) plain dvbapi-client granted (dvbapi_local, au=auto (1 reader))
2018/03/25 16:20:22 55B78E52 c   (dvbapi) dvbapi channelcache loaded from /etc/tuxbox/config/oscam.ccache
2018/03/25 16:20:22 55B78E52 c   (dvbapi) Detected /dev/dvb/adapter0/demux0 Api: 0, userconfig boxtype: 1 maximum amount of possible filters is 32 (oscam limit is 32)
2018/03/25 16:20:22 5C6694C4 h    (webif) webif: decompressed 177547 bytes back into 437176 bytes
2018/03/25 16:20:22 5C6694C4 h    (webif) HTTP Server running. ip=192.168.178.29 port=83
2018/03/25 16:20:23 5AC6DC9B r   (reader) ziggo [internal] card detected
2018/03/25 16:20:24 5AC6DC9B r   (reader) ziggo [internal] ATR: 3B 9F 21 0E 49 52 44 45 54 4F 20 41 43 53 20 56 35 2E 38 95
2018/03/25 16:20:24 5AC6DC9B r   (reader) ziggo [internal] Init card protocol T14, FI=2, F=558, D=1, N=0
2018/03/25 16:20:24 5AC6DC9B r   (reader) ziggo [internal] Calculated work ETU is 124.00 us reader mhz = 450
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 0 CAID: 1801 ECM_PID: 0032 PROVID: 000000
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 1 CAID: 1850 ECM_PID: 0096 PROVID: 000000
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 2 CAID: 0602 ECM_PID: 00C8 PROVID: 000000
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 3 CAID: 0604 ECM_PID: 012C PROVID: 000000
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 4 CAID: 0606 ECM_PID: 0190 PROVID: 000000
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 ecmpid 5 CAID: 1868 ECM_PID: 01C2 PROVID: 000000
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 found 6 ECMpids and 7 STREAMpids in caPMT
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 no suitable readers found that can be used for decoding!
2018/03/25 16:20:27 5AC6DC9B r   (reader) ziggo [internal] Buffers readed  0 bytes total time_us 3038220
2018/03/25 16:20:27 55B78E52 c   (dvbapi) Demuxer 0 found 6 ECMpids and 7 STREAMpids in PMT
2018/03/25 16:20:28 5AC6DC9B r   (reader) ziggo [internal] PLL Reader: ATR Fsmax is 6 MHz, clocking card to 4.50 Mhz (nearest possible mhz specified reader->mhz)
2018/03/25 16:20:29 5AC6DC9B r   (reader) ziggo [internal] detect irdeto card
2018/03/25 16:20:29 5AC6DC9B r   (reader) ziggo [internal] Irdeto SC 58 version 21 revision 1, patch level e
2018/03/25 16:20:29 5AC6DC9B r   (reader) ziggo [internal] caid: 0604, acs: 0.05, country code: NLD
2018/03/25 16:20:29 5AC6DC9B r   (reader) ziggo [internal] providers: 4, ascii serial: ##########, hex serial: ######, hex base: ##
2018/03/25 16:20:30 55B78E52 c   (dvbapi) Demuxer 0 no enabled matching ecmpids -> decoding is waiting for matching readers!
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [internal] WARNING: For Irdeto cards you will have to set 'mhz= 600' in oscam.server
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [internal] active providers: 4 (125644,ffffff,ffffff,ffffff)
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [internal] found card system irdeto
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] THIS WAS A SUCCESSFUL START ATTEMPT No  1 out of max alloted of 1
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] entitlements for provider: 1, id: 125644
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: FFE0, date: 2018/03/25 - 2018/04/24
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 000B, date: 2018/03/25 - 2018/10/11
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 0027, date: 2018/03/25 - 2018/10/11
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 0028, date: 2018/03/25 - 2018/10/11
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 01F4, date: 2018/03/25 - 2018/10/11
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 028A, date: 2018/03/25 - 2018/10/11
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 0384, date: 2018/03/25 - 2018/10/11
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 7FFE, date: 2017/07/19 - 2017/08/18
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: 7FFD, date: 2018/03/25 - 2018/04/04
2018/03/25 16:20:32 5AC6DC9B r   (reader) ziggo [irdeto] chid: FFD8, date: 2018/03/25 - 2018/10/11



een korte log van de laatste paar zaps

je ziet de er is contact en ecm's worden gevonden, maar beeldscherm blijft zwart op ketnet en tv5 na



ik had ook al een svrid getetst maar dat lost niets op



de server ziet zo uit,

Spoiler

[reader]
label = ziggo
description = Ziggo
protocol = internal
device = /dev/sci0
services = ziggo_basis
caid = 0604:xxxxxx
rsakey = 3C8633AACappieheinisduurderdanA
boxkey = 1appelsenperen8
detect = cd
mhz = 600
cardmhz = 2700
ident = 0604:000000,000001,000002,000003
group = 1,2
emmcache = 1,3,2



Edited by Tonskidutch
aanvulling kaartherkenning

Hollow Talk

Chior of Young Believers

Link to comment
Share on other sites


Hier OScam 11400 i.c.m. Ziggo. Geen probleem met de decodering. Ook niet met de oude 11377. Gebruik hier de laatste VTi 13.0.9 op alle VU+ apparaten. Er zijn in mijn regio klaarblijkelijk wel wat Ziggo issues. Zie wel heel veel Ziggo auto's in de buurt. Vandaag zelfs in mijn straat. Overal gaan de grote verdeelkasten open waar de wijkversterker in zit. De kleine verdeelkastjes laten ze ongemoeid.

Raspberry Pi 3B+ Argolis Triple Reader Kaartserver + Smargo

Vu+ Zero 4K DVB-S2X, Vu+ Zero 4K DVB-C/T2, DM525 Combo, DM920 UHD

VU+Ultimo4K BTE,  DM-One UHD, Ziggo, HD+, TV-Vlaanderen, ORF, TiVuSAT

13°E,19.2°E, 23.5°E, 28.2°E. Triax 88 en Triax 60

Link to comment
Share on other sites

Een ander mogelijk probleem is dat de kaart handmatig op 4.50 Mhz gezet is.

Normaal moet een Irdeto kaart op 6.00 Mhz draaien en soms gata hte op 4.50 Mhz niet goed.

In veel linux ontvangers is 6.00 Mhz niet altijd mogelijk en zou je hem op de dichts bij zijnde frequentie willen draaien.

Dit is meestal 5.40 Mhz.

Indien je in de config de kaart echter toch op 6.00 Mhz zet, zal oscam automatisch de dichts bij zijnde frequentie selecteren.



Link to comment
Share on other sites

@Tonskidutch

Misschien een oudere OScam installeren? Ik heb geen Ziggo internet..

Raspberry Pi 3B+ Argolis Triple Reader Kaartserver + Smargo

Vu+ Zero 4K DVB-S2X, Vu+ Zero 4K DVB-C/T2, DM525 Combo, DM920 UHD

VU+Ultimo4K BTE,  DM-One UHD, Ziggo, HD+, TV-Vlaanderen, ORF, TiVuSAT

13°E,19.2°E, 23.5°E, 28.2°E. Triax 88 en Triax 60

Link to comment
Share on other sites

13 minuten geleden zei Mimisiku:

Hier OScam 11400 i.c.m. Ziggo. Geen probleem met de decodering



kaart en internet separaat, aha



ga het eens testen, met een oudere versie, vind ik wel vreemd daar niemand daar melding over maakte

en die svrid?

Hollow Talk

Chior of Young Believers

Link to comment
Share on other sites

Ik gebruik de auto-load van srvid2.

Raspberry Pi 3B+ Argolis Triple Reader Kaartserver + Smargo

Vu+ Zero 4K DVB-S2X, Vu+ Zero 4K DVB-C/T2, DM525 Combo, DM920 UHD

VU+Ultimo4K BTE,  DM-One UHD, Ziggo, HD+, TV-Vlaanderen, ORF, TiVuSAT

13°E,19.2°E, 23.5°E, 28.2°E. Triax 88 en Triax 60

Link to comment
Share on other sites

srvid is nergens voor nodig, mag leeg blijven, is er alleen maar voor om in oscam zichtbaar te maken welke zender bekeken wordt, laat je het leeg dan krijg je alleen de zender naam niet te zien.



label                         = cardreader
protocol                   = internal
device                      = /dev/sci0
caid                          = 0604
box.....                      = 1122334455667788
rsa...... = 3C8633AAC0D367533DEC7BB2EEEDEB8CA3ADA52E58B99BB34672783277A1DAAC3B6106AD0909774E031B2A6E30195B437683AD0FC599B87D08CEA47BE1B6C76A
detect                        = cd
mhz                           = 540
cardmhz                    = 2700
group                          = 1

emmcache                 = 1,3,2,0
blockemm-unknown = 1
blockemm-g               = 1



........ aanvullen met de juiste text     zou al voldoende moeten zijn voor beeld

Link to comment
Share on other sites



neen hoor met OpenPli 6.1 stable en oscam 11400 geen resultaat en dezelfde weergave ) oscam webinterface beeld en op TV zwart (

p.s. kan het liggen aan dynamische RSA tenminste die melding gaf oscam

het is de tweede kaart van de abonnement houder

Hollow Talk

Chior of Young Believers

Link to comment
Share on other sites

waar komt bij jouw de 5644 vandaan, de regel hier onder is uit mijn log waar keurig 0604 staat



(ecm) local (0604@000000/000B/4BA3/4C:D464A876987813E932269D1FE83B2BCE): found (185 ms)



(ecm) dvbapi_local (5644@000000/000B/4B1A/4C:B1F1F74F0706CABA1C3C59C0787472C2): found (237 ms) by ziggo
Link to comment
Share on other sites

2018/03/27 20:08:26 0B1B5AD5 r   (reader) ziggo [irdeto] dvbapiau emmtype=shared, len=63 (hex: 0x3F), cnt=0: written (166 ms)
2018/03/27 20:08:31 4D1FD0F6 c      (ecm) dvbapiau (0604@000000/0027/4CBD/4C:9CBC6151131D92BE39F2D843200F914F): found (246 ms) by ziggo
2018/03/27 20:08:51 4D1FD0F6 c      (ecm) dvbapiau (0604@000000/0027/4CBD/4C:95E239C3DC541F5E209A23F8F8C809AD): found (246 ms) by ziggo

henkvd1

dat was hem  5644 was fout, heb nog eens alles gecontroleerd...

werruk:grin:
